    SpatDIF

    Spatial Sound Description Interchange Format

    Institute for Computer Music and Sound Technology (ICST)

    SpatDIF, the Spatial Sound Description Interchange Format, is an ongoing collaborative effort offering a semantic and syntactic specification for storing and transmitting spatial audio scene description. The SpatDIF core is a lightweight minimal solution providing the most essential set of descriptors for spatial sound scenes.

    SpatDIF, the Spatial Sound Description Interchange Format, is an ongoing collaborative effort offering a semantic and syntactic specification for storing and transmitting spatial audio scene description. The SpatDIF core is a lightweight minimal solution providing the most essential set of descriptors for spatial sound scenes. Additional descriptors are introduced as extensions, expanding the namespace and scope with respect to authoring, scene description, rendering, and reproduction of spatial sound.

    In computer music, many spatialization algorithms use a self-contained syntax and storage-format, wherein control messages (e.g. trajectories to move a sound virtually) programmed for one application are incompatible with any other implementation. This lack of a standardization complicates the portability of compositions and requires manual synchronization and conversion of control data - a time consuming affair. Incompatible data formats also prevent collaboration between researchers and institutions. The general idea is to develop of a format to describe, store and share spatial audio scenes across 2D/3D audio applications and concert venues. The ICST forms part of the team specifying and developing spatialization tools that use and promote the use of SpatDIF in the electronic music community.

    Details

    • Research Focus
      • FSP Technologie und Musikalische Praxis
    • Project Lead
      • Jan Schacher (ICST)
    • Team
      • Chikashi Miyama (ICST)
    • Cooperations
      • BEK - Bergen Center for Electronic Arts, Norway;
      • CNMAT, Center for New Music and Audio Technologies, Universty of California, Berkeley; (ehemalig)
      • GMEA - Groupe de Musique Electroacoustique de Albi, France; GMEM - Groupe de Musique Electroacoustique de Marseille, France (ehemalig)
      • McGill University, Montreal, Canada; (ehemalig)
      • ZKM - Zentrum Kunst und Medien, Karlsruhe, Institut für Musik und Akustik;
    • Resources
      • Project website
    • Duration

      01.01.2007 – 31.12.2020

    • Research Approaches
      • Applied research
      • Artistic-scientific research
    • Disciplines

      Music

    • Keywords

      Composition Tools, 3D audio, standardisation, spatial sound

    • More Links
      • Jan C. Schacher / Chikashi Miyama / Trond Lossius: The SpatDIF Library – Concepts and Practical Applications in Audio Software. In: Proceedings of the joint International Computer Music and Sound and Music Computing Conference (ICMC-SMC), Athens, Greece,
      • Chikashi Miyama / Jan C. Schacher / Nils Peters: Spatdif Library – Implementing the Spatial Sound Descriptor Interchange Format. In: Journal of the Japanese Society for Sonic Arts, Vol. 5 No .3, pp.1-5, December 2013.
      • Nils Peters / Trond Lossius / Jan C. Schacher: The Spatial Sound Description Interchange Format: Principles, Specification, and Examples. In: Computer Music Journal, Volume 37, Issue 1, Spring 2013.
      • Nils Peters / Trond Lossius / Jan C. Schacher: SpatDIF: Principles, Specification, and Examples. In: Proceedings of the 9th International Sound and Music Computing Conference, Copenhagen, Denmark, 11-14 July 2012.
      • Nils Peters / Trond Lossius / Jan C. Schacher / Pascal Baltazar / Charles Bascou / Tomothy Place: A Stratified Approach For Sound Spatialization. In: Proceedings of The 6th Sound and Music Computing Conference, Porto, 23-25 July 2009.
      • Spatdif externals for MAxMSP and Pure Data
      • code.zhdk.ch/git/spatdiflib.git
      • code.zhdk.ch/git/spatdifrenderer.git
    • Downloads
      • SpatDIF_poster_SMC2009.pdf
      • SpatDIF_poster_SMC2012.pdf

    Output

    • Aufsätze in Tagungsakten (Vortrag, Keynote)

      Miyama, Chikashi / Dipper, Götz / Krämer, Robert & Schacher, Jan C. (2016): «Zirkonium, SpatDIF, and Mediaartbase.de; an Archiving Strategy for Spatial Music at ZKM». Proceedings of the 13th Sound and Music Computing Conference. 318–325. Online unter: http://chikashi.net/wp-content/uploads/2013/05/smc2016.pdf.

    • Aufsätze in Tagungsakten (Vortrag, Keynote)

      Schacher, Jan / Peters, Nils / Lossius, Trond & Miyama, Chiskashi (2016): «Authoring Spatial Music with SpatDIF Version 0.4». Proceedings of the 13th Sound and Music Computing Conference (SMC). 415–421. Online unter: https://doi.org/10.5281/zenodo.851297.
